X stroke : 3550 mm, 139.8"
Y stroke : 2340 mm, 92.1"
Z stroke : 800 or 1200 mm, 31.5 or 47.2"
Spindle power : 17.6 or 25 kW (S6), 23.6 or 33.5 hp (S6)
Spindle speed : 0 - 10000
Tools : 15 kg maxi
Water supply : 40 l/mn, 10.5 gal(US)/mn
Air supply : 12 m3/h > 6 bar, 423 ft3/h > 87 PSI
Power supply : 34 or 44 kW / 45 or 59 hp , 400 - 480 V , 50 - 60 Hz
Lubrication : Centralized & automatic
Table dimensions : 3375 mm x 2040 mm, 132.9 x 80.3"
All-in dimensions : 6440 x 6250 x 3450 mm, 253.5 x 246 x 135.8"
Weight : 10000 kg
