TC725 TOPS

High Production 5-axis CNC Saws

You are cutting a lot of 2'' to 8'' slab? the TC725 TOPS is what you are looking for! Bigger motor combine to the automatic loading and unloading system make the TC725 the production machine you have been looking for.

Faster
Stronger
Better
Specifications
Dimensions
Specifications

Minimum disc diameter : 400 mm, 15.7"

Maximum disc diameter : 750 mm, 29.5"

Bore diameter : 60 mm, 3.36"

Flange diameter : 215 mm, 8.46"

X stroke : 3880 mm, 157.7"

Y stroke : 2600 / 3700 mm, 102.4 / 145.6"

Z stroke : 500 mm, 19.6"

Maximum thickness : 200 mm, 8"

Spindle power : 23.2 kW (S6), 30.8 hp (S6), 155 Nm, 1363 lbf.in

Spindle speed : 0 - 6000

Tools : 10 maxi (TH150)

Water supply : 25 l/min, 6.6 gal (US)/mn

Air supply : 200 l/mn > 6 bars min, 53 gal (US)/mn > 87 PSI

Power supply : 38.5 kW / 51 hp, 400 - 480 V, 50 - 60 Hz

Dimensions

Table dimensions : 3600 x 2000 mm, 141.7 x 78.7"

All-in dimensions : 6310 x 4770 x 3050 mm, 248.5 x 187.8 x 120"

Weight : 8500 kg
